HAIZHONG GLOBAL supplies semi trailers from China.
- Loading Capacity30T-60T
- Axle3 axles
Product Description
HAIZHONG GLOBAL supplies semi trailers from China.
Tri axles 60ton rear end dumper semi trailer tippers are using high strength steel material, all the spare parts, just like: landing gear, axles, tyres, oil cylinders, are using world famous brands.
The loading capacity for rear end dumper tipper is 30ton-100ton, you can choose 2 axles, 3 axles, 4 axles, 5 axles, 6 axles, etc according to your needs.
Specifications
| Material | high strength steel |
|---|---|
| Loading Capacity | 30T-60T |
| Axle | 3 axles |
| Tire | 12 units, 12.00R22.5 or 315/80R22.5 |
| Rim | 9.00-22.5 or 9.75-22.5 |
| Suspension | Mechanical, Airbag suspension |
| Spring Leaf | 90 (W) mmx13 (Thickness) mmx10 layers or 100mmx12mmx12 (specially intended for overseas markets) |
| King Pin | 2.0 or 3.5 inch (bolted or welded) |
| Landing Gear | 28tons (double-speed) |
| Bottom Side Beam | 16mm or 18mm steel channel |
| Brake Chamber | Relay valve; T30/30+T30 spring brake chamber, 45L air tank |
| Twist Locks | 4,8,12 sets (lifting or screw type) |
| Valve | Specially intended for oversea market |
| ABS | Optional |
| Light | LED light (specially intended for oversea market) |
| Voltage | 24V |
| Tool Box | 1m x 0.5m x 0.5m (The tool box contains 1 tire spanner, 1 gudgeon sleeve and 1 cranking bar. Its size can be tailored to suit your needs) |
| Painting | Sandblasted, anti-rust chassis surface is available with 1 layer of anticorrosive primer and 2 layers of top coats |
Specifications shown are reference configurations. Before quoting, we confirm the exact specification with you — dimensions, axle count, tyre size, kingpin size, suspension, ABS and options.
